Steps for
Building – Winnipesaukee Scenic Railroad’s #1008
By James E. Harter Jr.
This modeling project has been designed to allow
the model railroad enthusiast to build a highly detailed and accurate
model of the Plymouth and Lincoln Railroad’s Winnipesaukee Scenic
Railroad #1008. The Plymouth and Lincoln Railroad is the parent company
of the Hobo Railroad of Lincoln N.H. and the Winnipesaukee Scenic
Railroad of Weirs, New Hampshire. This project pack is designed for
building Winnipesaukee Scenic Railroads #1008. Be advised that some
minor modifications to the engine frame and the optional snowplow are
required when building this engine. Also it is sometimes difficult to
find the Atlas switcher engines, you may have to check with more than
one hobby shop.
- Atlas S1 switcher engine preferably an
undecorated version.
- Details West – Air Horn AH-190 Leslie RSL-3L-R
#235-190*
- Details West – Snow Plow PL-150 “WEED-CUTTER”
#235-1508
- Details West – Steplights SL-172 Step Lights
#235-172
- Custom Finishes – 201 Sinclair Antenna -
#247-201*
- CAL-SCALE MARKER LAMPS MA-280 (1 pair) -
#190-280*
- PRECISION SCALE Co. 48291 Clear jewels .053
(12 per envelope) - #585-48291*
- Detail Associates – LT 1012 Dual Headlight “Pyle
conversion plate” - #229-1012
- One Kadee #5 for front and one Kadee #26 for
rear (needed to extend over snowplow), (#380-5, #380-26*)
- Paints Floquil Primer, CSX Black Gloss,
Central Wisc. Maroon Gloss, CNW Yellow, Testors Gloss Clear spray
- Tamiya Color )PC-6 Yellow paint for
polycarbonate material (plastic hand rails – paint resists cracking
and flaking)
- Custom Decal Sheet. - NECR#004R1 Included
- One bottle of Microscale – MICRO SET (blue
label), and MICRO SOL (red label) setting solution for irregular
surfaces).
- One bottle of Scalecoat Paint stripper. This
item only necessary if an undecorated engine is unavailable.
- OPTIONAL - decoder for DCC upgrade. Either NCE
Decoder ATLS4 or TTX AtlasSW (same unit different label)
- OPTIONAL – Miniatronics Ultra Bright White
LED’s #12-300-02
(* Walthers numbers
#MMM-PPPPP where MMM is a manufacturers code and PPPPP is a part number) |
